B&R 8LSA55 Synchronous Motors 8LSA55.DA030S200-3, 8LSA55.DB030S000-3 For Servo Driver System

Dengfeng (Zhaoqing) Trading Co., Ltd
Contact Now
    Buy cheap B&R 8LSA55 Synchronous Motors 8LSA55.DA030S200-3, 8LSA55.DB030S000-3 For Servo Driver System from wholesalers

    Buy cheap B&R 8LSA55 Synchronous Motors 8LSA55.DA030S200-3, 8LSA55.DB030S000-3 For Servo Driver System from wholesalers
    • Buy cheap B&R 8LSA55 Synchronous Motors 8LSA55.DA030S200-3, 8LSA55.DB030S000-3 For Servo Driver System from wholesalers
    • Buy cheap B&R 8LSA55 Synchronous Motors 8LSA55.DA030S200-3, 8LSA55.DB030S000-3 For Servo Driver System from wholesalers
    • Buy cheap B&R 8LSA55 Synchronous Motors 8LSA55.DA030S200-3, 8LSA55.DB030S000-3 For Servo Driver System from wholesalers

    B&R 8LSA55 Synchronous Motors 8LSA55.DA030S200-3, 8LSA55.DB030S000-3 For Servo Driver System

    Ask Lasest Price
    Brand Name : B&R
    Model Number : Synchronous motor 8LSA55.DA030S200-3
    Certification : CE UL cURus E360421 Servo and stepper motors - Component
    Price : USD 1000 -20000 piece as depend on booking price
    Payment Terms : D/A, D/P, T/T, Western Union
    Supply Ability : 5 sets 10 days
    Delivery Time : 3-70 working days
    • Product Details
    • Company Profile

    B&R 8LSA55 Synchronous Motors 8LSA55.DA030S200-3, 8LSA55.DB030S000-3 For Servo Driver System

    8LS55...-3 three-phase Synchronous motors:

    Original 8LSA55.DA030S200-3


    DESCRIPTION:


    Synchronous motor, number of pole pairs: 4 pairs, nominal speed: 3,000 rpm, stall torque: 12.500 Nm, motor with holding brake, smooth shaft angled connector (swivel), centering diameter 130 mm, j6 fit (self-cooling, construction type A), IP64 protection, without oil seal 560 VDC, brake holding torque: 15.00 Nm, EA ind. 32-line single-turn. V2

    8LSA55...-3 - Standard motors(Others)


    8LSA55.DA030S000-3
    8LSA55.DA030S200-3
    8LSA55.DB030S000-3
    8LSA55.DB030S200-3
    8LSA55.DA030S100-3
    8LSA55.DA030S300-3
    8LSA55.DB030S100-3
    8LSA55.DB030S300-3

    Holding brake
    Holding torque of brake MBr [Nm]15
    Mass of brake [kg]1.47
    Moment of inertia of brake JBr [kgcm2]1.66
    Recommendations
    ACOPOS 8Vxxxx.xx...1090
    ACOPOSmulti 8BVIxxxx...0110
    ACOPOS P3 8EIxxxx...8X8X
    Cross section for B&R motor cables [mm2]1.5
    Connector size1
    Options
    Connection typeSingle-cable solution
    Connection directionSwivel, SCS
    EncoderDA 2.2 inductive 32-line single-turn
    Shaft endSmooth shaft
