B&R X20 PLC B&R X20cCP1382-RT For Power Link Controller System, good quality

Ask Lasest Price
Brand Name :	B&R
Model Number :	X20 PLC X20cCP1382-RT
Certification :	CE UL cURus E360421 Servo and stepper motors - Component
Price :	USD 500 -20000 piece as depend on booking price
Payment Terms :	D/A, D/P, T/T, Western Union
Supply Ability :	5 sets 10 days
Delivery Time :	3-70 working days

Add to Cart

Product Details
Company Profile

B&R X20 PLC B&R X20cCP1382-RT For Power Link Controller System, good quality

B&R X20PLC X20cCP1382-RT:

DESCRIPTION:

Intel x86 400 MHz compatible with integrated I/O processor
Ethernet, POWERLINK with poll-response chaining and onboard USB
1 slot for modular interface expansion
Onboard reACTION Technology
30 digital inputs/outputs and 2 analog inputs integrated in the device
2 GB onboard flash drive
256 MB DDR3 SDRAM
Fanless
No battery
Backed-up real-time clock

The X20 Compact controller series is characterized by 3 integrated I/O modules. The device is equipped with 30 different digital inputs/outputs and 2 analog inputs. 1 analog input can be used for Pt1000 resistance temperature measurement.

In addition, the X20CP1382-RT has ultrafast onboard reACTION Technology. reACTION Technology makes it possible to control the integrated I/O channels with response times down to 1 μs. With this new IEC 61131-2 compatible technology, particularly time-critical sub-tasks can be implemented in standard hardware, simultaneously making it possible to reduce costs by optimally reducing the load on the controller and allowing it to be scaled down accordingly.

The X20 Compact controller is equipped with an Intel x86 400 MHz compatible processor, 256 MB RAM and 2 GB built-in flash drive. The FRAM for storing remanent variables has 32 kB available. A fanless and battery-free design ensures maintenance-free operation.

The controller is equipped with Ethernet, 2x USB and an RS232 interface. In addition, POWERLINK and CAN bus are available as integrated interfaces. For additional fieldbus connections, the controller can be expanded with an interface module from the X20 standard portfolio.

B&R X20PLC (Others)

x20cCP1382-RT

x20CPc0410

x20cBB52

x20cBB57

x20cPS9600

x20cCP1301

x20cp3687x

X20AC0SH2.0010

x20cp3584

x20cp3685

B&R ID code	0xE707
Cooling	Fanless
Status indicators	CPU function, Ethernet, POWERLINK, RS232, CAN bus, CAN bus terminating resistor, PLC power supply, I/O power supply, I/O function per channel
Diagnostics
Outputs	Digital outputs: Yes, using LED status indicator and software (output error status)
CPU function	Yes, using LED status indicator
CAN bus data transfer	Yes, using LED status indicator
RS232 data transfer	Yes, using LED status indicator
Inputs	Analog inputs: Yes, using LED status indicator and software
Ethernet	Yes, using LED status indicator
I/O power supply	Yes, using LED status indicator
POWERLINK	Yes, using LED status indicator
Supply voltage monitoring	Yes, using LED status indicator
Temperature	Yes, using software register
Terminating resistor	Yes, using LED status indicator
Support
Controller redundancy	No
ACOPOS support	Yes
reACTION-capable I/O channels	Yes
Visual Components support	Yes
Power consumption without interface module and USB	5.8 W
Power consumption for X2X Link power supply	0.8 W
Power consumption
Internal I/O	2.3 W
Additional power dissipation caused by actuators (resistive) [W]	-
Type of signal lines	Shielded lines must be used for all high-speed digital inputs/outputs, line length: Max. 20 m
Certifications
CE	Yes
UKCA	Yes
ATEX	Zone 2, II 3G Ex nA nC IIA T5 Gc IP20, Ta (see X20 user's manual) FTZÚ 09 ATEX 0083X
UL	cULus E115267 Industrial control equipment
HazLoc	cCSAus 244665 Process control equipment for hazardous locations Class I, Division 2, Groups ABCD, T5
DNV	Temperature: B(0 to 55°C) Humidity: B(up to 100%) Vibration: B(4 g) EMC: B(bridge and open deck)
LR	ENV1
KR	Yes
ABS	Yes
BV	EC33B Temperature: 5 - 55°C Vibration: 4 g EMC: Bridge and open deck
EAC	Yes
